Shimming your Metabones CINE Smart Adapter

I’ve been a long time Metabones customer. I purchased my first Smart Adaptor (the MK2, which I still own) back in 2012 to use on my Sony FS100 and Sony NEX5. I’ve also owned various versions of their Speed Boosters (Nikon to MFT, Nikon to BMCC, Nikon to BMPCC, Canon to BMPCC, Canon to E Mount) and some of their “Dumb” Adaptors (Nikon G to MFT, Nikon G to E Mount) over the years.

Metabones build quality has always been pretty solid and they has been my “goto” adaptor and ones that I often recommend when anyone asks.

Until recently I was using the “EF – E Mount T Smart Adapter (Mark IV)” but I sold that after buying the Sigma MC11 as most of my EF glass is from Sigma and I get much better AF performance with the MC11 on the A7RII and A6300.

With the launch of the new CINE Series mounts I thought I’d grab one to use on my Sony PXW-FS5 as I love the idea of locking my lens in place and having better manual focus control. Locking the mount and the lens means there is no play in the lens when you are pulling focus. This is a real issue when using “stills” lenses.

So I ordered a “Canon EF Lens to Sony E Mount T CINE Smart Adapter” and when it arrived I ran a few tests and I was a little disappointed to find the following issue: With the Sigma MC11, my Sigma 18-35 f1.8 is Parfocal. It holds focus throughout the zoom range. With the Metabones “Canon EF Lens to Sony E Mount T CINE Smart Adapter” it does not hold focus. I remember that this was also the case with the “EF – E Mount T Smart Adapter (Mark IV)”.

So I checked the flange focal distance (FFD) of the adaptors and here is what I found:

Sony E Mount FFD is 18mm.
Canon EF FFD is 44mm.
This means the adaptor needs to be 26mm to fill the gap.

When I measure, with a vernier calliper, the Sigma MC11 it is spot on 26mm. As it should be.
When I measure the Metabones EF – E Mount T Cine Smart Adaptor is reads 25.9mm. So it’s out by 0.1mm.

That’s a pretty big difference with it comes to lens mounts an is enough to cause any parfocal lens to shift focus as you zoom.

Why is this? Seems silly to have a Cine mount that locks the lens in place but is not accurate for focus work. If the mount and adaptor were old I could understand it being out by that much due to wear and tear but this is a new adaptor.

So I contacted Metabones Support. After a week I’d heard nothing back. So I though “Can I shim the mount to correct this?”

Looking at the adaptor, the front mount plate seemed the best option to shim. So I removed it to have a look how it was assemble. What I found was a pretty simple design that looked easy to shim and as it turned out it was and the result was I was able to correct the FFD and the Sigma 18-35 is now parfocal again.

Below are the steps I took (warning, this may void your warranty and you follow these steps entirely at your own risk).

Things you’ll need:
1.5mm hex key (normally supplied with the adaptor)
Craft knife or scalpe blade
Cutting mat
Hole punch or sharp point (a small Phillips screw driver will do)
Strong film to make the shim from (I used so lighting gel)

Step 1

Remove the 5 screws from the front of the mount with a 1.5mm hex key and carefully lift out the mount plate. Careful not to drop the small spacers that support the mount. Leave them inside the adaptor.

Step 2

Now over to the cutting mat use the mount plate as a template to cut your shim from the film. I used some lighting gel film.

Step 3

Cut your shim to match the front plate. In my case I cut 2 to get the right thickness.

Step 4

Once you have the shims cut you’ll need to make holes for the screws. Best is to use a hole punch tool or a sharp point but a small Phillips head screwdriver will also do the trick.

Step 5

Now inset the screws through the mount and the shims. As the holes in the shims are tight they should hold the screws in place and the shims should align nicely.

Step 6

Carefully flip the mount plate over and align the screws with the holes in the supports inside adaptor. Tighten all the screws with the 1.5mm hex key alternating sides as you do so.

That’s it. Now test to see if you have shimmed it enough.

As with any mount over time the mounting and un-mounting of lenses will cause wear and tear and the accuracy of the mount will start to drift so you might need to re-shim the mount in the future. Now you know how.

Hope that’s been of some help.


Rigging your Sony A6300

I’ve been shooting with Sony mirrorless/E mount systems since the release of the Sony NEX5. A lot has changed since then and there are so many more options available today. Over the past few years I’ve shot on many of those options including the Sony FS100 and FS700, the Sony A7 Series and even the Sony FS5.

Since the release of the Sony A6300 this little camera has become my goto camera for corporate doco work where I need to travel super lightweight. I thought I’d share how I rig this camera for that use as well as how it can be rigged for use on a gimbal, like the DJI Ronin.

The core of my rig is based around the Small Rig 1661 cage. As full disclosure, I was one of a few people who give Small Rig feedback on the original cage and some of my requests were included in the new cage. Small Rig supplied me with the new cage. I’m not paid by Small Rig and all other parts have been purchased, and are currently being used, by myself. I don’t recommend products I’m not happy to use myself.

I’ve created a shopping list with notes if you are looking to pick-up any of the parts:
View list on Amazon UK
View list on Amazon US

The parts are also available direct from Small Rig.

The monitor I’m using is the smallHD 501, the wooden handle is from Tilta, wireless follow forces is the Lenzhound from Motion Dogs and the bag is the LowePro ProTactic 350 AW which is perfect as a carry on bag even with regional / budget airlines.


Blackmagic Camera Update - 2.1

So it’s been a long time coming but this update really does round off the Blackmagic Cinema Camera (BMCC) and Blackmagic Pocket Cinema Camera (BMPCC) nicely, and with an all new installer to boot.

So what is new in 2.1? Lets get in under the skin of it.

First off the BMCC now has the same Lossless Compression when shoot in RAW as the BMPCC. This is big. It means you can shoot for longer on your SSD and you’ll have much less data to wrangle. The compression saves about 30% over the original RAW (2.5-3.5MB per frame vs 5MB previously – depending on the content of the frame) while still retaining all the data.

Next we have frame guides. This has been a long time request and a welcome addition. We now have a wide selection of frame guides: HDTV (this was available before), 4×3, 2.40:1, 2.39:1, 2.35:1, 1.85:1, and Thirds. All the aspect ratio guides are based on the blanking options in Resolve. It’s also be nicely implemented in that they can be turned on or off independently on the internal LCD and the external monitor. So you can view them just on the LCD if you’d like to record a clean signal externally or you can keep the LCD screen clear and only display the guides on the external monitor.

Additional fixes and tweaks:
A nice little user interface addition was also added to speed up menu access. Holding down MENU will now bypass Dashboard and go straight into settings. Pressing it again returns you to shooting mode. Skips a few extra clicks when under pressure.

The cameras now remember the peaking status after rebooting. This was an annoying little bug on the BMPCC and it’s nice to see that has been fixed.

Time remaining estimate when shooting RAW is now more inline with real world shooting. The time remaining when shooting compressed RAW has always been an estimate. It can’t be accurate because the nature of the compression means that the file size changes depending on what is in frame. A simple white frame is much smaller when compressed than a frame with lots of colour and detail.

What has happened is BM have adjusted the math on the estimation so it’s closer to real world shooting. There are no change to the compression.

Generally speaking you’ll get a little more recording time than the estimated time displayed on camera.

Here is an example test I ran on 2 different version of the firmware, both shooting the same static scene:
BMPCC running 1.9.10
1080p24
13min remaining on screen after fresh format of 64BG card
Stopped recording with card full at: 21:51:18
31482 frames (61GB)
Frame size: 1.9MB (1,931,392 bytes)

BMPCC running 2.1
1080p24
18min remaining on screen after fresh format of 64BG card
Stopped recording with card full at: 21:50:08
31448 frames (61GB)
Frame size:1.9MB (1,941,184 bytes)

As you can see there is no change in the RAW compression. Just an adjustment to the math on the time remaining estimates.

The BMPCC also gets Japanese and Chinese language menu support. Something I’m guessing will roll out to the other cameras in the future.

Having used the BMCC (along with the BMPCC and BMPC4K) since they started shipping it’s really nice to see how far we have come since version 1.1 of the firmware. For me this update completes the camera. The only thing I’d really like to see is the ability to record in Film colour space while outputting Video colour space to my external monitor / EVF. I’m sure those who shoot anamorphic would like more tools (4×3 and de-squeeze) but I’m not sure the BMCC has much processing power left.

Get the update here:
www.blackmagicdesign.com/support/family/professional-cameras

For advice on the update process see this thread:
forum.blackmagicdesign.com/viewtopic.php?f=2&t=28413


Blackmagic Camera Update - 1.9.3

So it's finally here, the update everyone has been waiting for and with so much more to offer.

Blackmagic has just released firmware update 1.9.3 for the BMCC and BMPCC. After testing it over the past week here is what you get in the new update. It brings time remaining, audio meters and histogram, first seen on the BMPC4K in firmware 1.9, to the BMCC and BMPCC. It also adds a few other nice little touches that have long been requested.

bmpcc_screen

These new additions have been implemented as a bar across the bottom of the screen. This bar can be shown and hidden with a simple swipe up and down on the screen on the BMCC or clicking the up or down buttons on the BMPCC. When using manual lenses the IRIS button will also show and hide the display. This means we can now monitor out audio and set the correct gain to begin with. This is a big plus for those who shot on their own or without a sound person on set.

The histogram is a nice addition as it gives you more detail on your exposure. Until now we have only had zebras to help us judge what elements might be clipping.

Something to note on the histogram is that it is based on the "processed" image data so it is affected by the ISO you select where as the zebras reflect sensor data, showing clipping at the sensor level and are not affected by your ISO choice.

Time remaining is a simple hours and minutes display that show how much you can still record in the currently selected format. When shooting RAW on the BMPCC the time is approximate a the RAW frames vary in size depending on what is in the frame due to how the Compressed CinemaDNG writes data to the file.

Looking at the other additions, we now have more shutter angles available. This opens up some nice creative opportunities as well as dealing with technical issues like flicker when working under some artificial light sources.

Shutter Angles:
11.25°, 15°, 22.5°, 30°, 37.5°, 45°, 60°, 72°, 75°, 90°, 108°, 120°, 144°, 150°, 172.8°, 180°, 216°, 270°, 324°, 360°

Second we now have more white balance options. So you'll be able to dial in a more accurate white balance on set.

White Balance options:
2500K, 2800K, 3000K, 3200K, 3400K, 3600K, 4000K, 4500K, 4800K, 5000K, 5200K, 5400K, 5600K, 6000K, 6500K, 7000K, 7500K, 8000K

A few issues
So with the added white balance and shutter angle options you'll be spending more time in the menus...

On the pocket it's a minimum of 4 clicks before you can change the white balance. You also can't see what the effect of the change is until you exit the menu, another 2 clicks (or hitting the record button once). If you then need to adjust it again it's 4 more clicks. Seems very long winded.

The camera returns to the last menu item if you exit by hitting the record button. Problem is that if you hit record while in the menu it starts to record.

So now if you hit menu then navigate to the white balance and make a change, then hit the record button to exit, when you hit the menu it returns you to the white balance setting (or what ever the last setting you used). One click in, onc click out. This could be a huge time saver but sadly it only really works without a card in the camera. What Blackmagic need to do is perhaps set the menu button on the BMPCC to exit the menu rather then go up a level.

Another issue is that the histogram does not show clipping. So if you have your zebras turned off the histogram can be a little deceiving as you could be clipping your highlights without knowing.

These features and the addition of other ProRes codecs in firmware 1.8.2 really make these cameras shine. It's good to see Blackmagic are still committed to their early cameras like the BMCC while developing new ones like the URSA.

Get the update here: www.blackmagicdesign.com/support/family/professional-cameras


SSD storage for you BMCC


With the Blackmagic Cinema Camera using SSDs as its storage medium I've been looking for a way to safely store my SSDs while traveling or when not in use.

There are many cases that will hold a single drive but I normally have 2 - 4 drives with me on set so I was looking for a bettet solution. I then cam across the Orico PHC-35 HDD protection box. It lets you store up to 4 SSDs in a case that is very reminiscent of a Betamax case (yeah I'm showing my age). Fits perfectly in my camera case alongside my smallHD DP6 monitor and my tool bags.

Available in 4 colours (Grey, Pink, Blue and Green) and at £5.99 they are really inexpensive.

Grab them on Amazon (UK) - Also available on Amazon US / DE / IT / FR.

Check out the other kit I use on my Amazon UK Store and my Amazon US Store

Ethical Statement


DaVinci Resolve on a Hackintosh – Part 3

The Benchmarks

In Part 1 I explained my thinking behind building a Hackintosh and listed the parts. Part 2 covered the build. Now lets look at how this machine performs compared to other known systems.

First lets compare some Geekbench scores. It's a good comparison as Geekbench tests the system but it's not really a great test for real world operations like running DaVinci Resolve. It also does not take into account what GPU you have installed.

You can find scores for standard Mac systems here: browser.primatelabs.com/mac-benchmarks

Lets look at the 2 systems I now have.

MacBook Pro (Late 2011 17" model)

Intel Core i7 2.5GHz
8GB 1333 MHz DDR3 RAM
AMD Radeon HD 6770M 1GB Graphics Card
SSD System Drive

This machine manages a Geekbench Score of 10457 (32bit mode) - That is pretty close to the standard system listed.

Hackintosh

Intel Core i7 3.5GHz
Asus P8Z77-V Premium Motherboard
16GB RAM
2 x EVGA Geforce GTX 670 4GB FTW
SSD System Drive

Stock set-up running at 3.5GHz with RAM running a 1333MHz it manages a Geekbench score of 13153 (64bit mode)
That's about the same as the current 27" iMac.
Over-clocked at a stable 4.2GHz with RAM running at 1600MHz it manages a Geekbench score of 15687 (64bit mode)
That's closer to a Mac Pro (Mid 2010) with 6 core Intel Xeon processor

I'm happy with that.

Now lets look at some real world tests by running the Standard Candle Test in Resolve 9.1.4.

MacBook Pro

No corrections = 24 FPS

4 blur nodes = 7 FPS
8 blur nodes = 4 FPS
16 blur nodes = 2 FPS
32 blur nodes = 1 FPS
64 blur nodes = 0.5 FPS

NR is not supported on ATI cards

Hackintosh

No corrections = 24 FPS

4 blur nodes = 24 FPS
8 blur nodes = 24 FPS
16 blur nodes = 24 FPS
32 blur nodes = 14 FPS
64 blur nodes = 7 FPS

1 NR node = 20 FPS
3 NR nodes = 7 FPS
6 NR nodes = 4 FPS

With this set-up I'm running DaVinci Resolve and colour grading RAW CinemaDNG footage from the Blackmagic Cinema Camera. Resolve is able to playback in realtime with 6 or 7 nodes, including noise reduction without a hitch.

Is this a system I'd install in a high end post production facility? No, not at all. For mission critical commercial work you would want a dedicated high end Mac Pro with a Cubix Expansion Chassis for your GPUs or you would be running a Linux based system. These systems come at a huge cost tho. Not a problem if you clients can afford to fund them.

In my case this system is used for my own personal projects and for work where clients can't afford having their post production done in a high end facility. It's stable and it earns it's keep. It's better than and iMac and while we wait for the New Mac Pros to start shipping I'm able to comfortably work with RAW CinemaDNG footage at 2.5k. Can't ask more than that for the £2350 price tag.

That price could easily be lowered if you already own a display and you don't need Thunderbolt.

By using a motherboard without Thunderbolt and only installing a single GTX670 2GB card (using a cheaper graphics card like the GT640 for the GUI) you would bring the cost down to the £1k mark. View my amazon store for the parts list on a budget build.

If you are interested in building your own Hackintosh I've listed all the parts I used on my Amazon UK Store and my Amazon US Store.

For help with your build and advice on other components check out the forums on www.tonymacx86.com

Ethical Statement


DaVinci Resolve on a Hackintosh - Part 2

The Build

In Part 1 I explained my thinking behind building a Hackintosh and listed the parts. So lets get into the build.

When I was growing up many of my friends at school had built their own PCs. It was never something that interested me. In the early 90's I started work as an art director at TBWA and the Macintosh was our system of choice and has been mine ever since. So I had never built my own PC. When the parts arrived I was a little nervous but thought "how hard can this be?". Assembly was pretty straight forward and I had the system built in an afternoon. If you can use a screw driver and can read then you should  no issues at all assembling the parts.

Next step was getting the OS up and running. I had spent a lot of time on the tonymacx86.com forum reading other users posts, researching my components and planning the build. The forum, like most forums, is filled with people having issues. Many of those come from simply not following instructions. There are also a lot of very knowledgeable people on the forum and in most cases you can find a solution to your problem without even asking a question. tonymac86 and the rest of the team have developed the process over the years that it's now pretty straightforward. Worth donating to their site if it's useful to you. If you use parts that have been tried and tested and follow the instructions you should have a machine up and running in a few hours.

So I began the process... My main guide was this: UniBeast: Install OS X Mountain Lion on Any Supported Intel-based PC

With OS X 10.8.3 most components on my list work out of the box.

What you need:
1. A purchased copy of OS X Mountain Lion (get it from the Mac App Store)
2. A USB Flash Drive to install UniBeast and the OS X instlled onto
3. MultiBeast to install the bootloader and drivers

My first task was to flash the motherboard with an updated bios. You don't need to do this on Gigabyte motherboards. The ASUS motherboard I chose needs this as the machine will kernel panic when booting as the OS tries to set-up power management. It's a quick and simple process. You can download the updated BIOS here: biosrepo.wordpress.com/asus/z77 and the process to flash the BIOS is explained here: event.asus.com/2012/mb/usb_bios_flashback_guide.

So now the machine is ready for installation. Our next step is to create a bootable USB flash drive. Over to my MacBook Pro, where I had purchased OS X Mountain Lion, and run the latest version of UniBeast. Follow the steps in Step 2 of the UniBeast Guide and create a bootable USB flash drive with latest version of OS X (10.8.3 at the time).

Back over to the Hackintosh. For the set-up you need to use the onboard graphics card ports. I connected my Asus PB278Q 27"display to the display port on the motherboard. It might be best to remove the GeForce GPUs for the set-up tho I have managed to reinstall the OS with them connected.

You now need to make sure the BIOS is set up correctly. This is pretty simple. Powered up the machine holding F2. This will bring you to the BIOS set-up. Now hit F5 to set the BIOS to it's defaults. You need to make a few changes from the default settings so now you need to hit F8 to go to the advanced menus. These are the changes you'll need to make:
Advanced -> SATA Configuration -> SATA Mode Select -> AHCI
Advanced -> SATA Configuration -> Set any SATA ports that need to be hotswapable
Advanced -> System Agent Configuration -> Graphics Configuration -> Primary Display: iGPU (you need to switch this to PCI-E after installation)
Advanced -> System Agent Configuration -> Graphics Configuration -> iGPU Memory -> 64MB
Advanced -> USB Configuration -> Intel xHCI -> Auto
Advanced -> USB Configuration -> EHCI Hand-off -> Enabled
Advanced -> Onboard Devices Configuration -> HD Audio Controller -> Enabled
Advanced -> Onboard Devices Configuration - Front Panel Type -> HD
Advanced -> Onboard Devices Configuration - SPDIF Out Type -> HDMI

Reboot and follow steps in Step 3 of the UniBeast Guide.

So now you should have your OS installed. We are almost there. For the Hackintosh to work we need to install some bootloaders and extensions. These allow OS X to run the Hackintosh hardware. Things like audio and networking. The latest version of MultiBeast has all of this covered.

Follow the steps in Step 4 of the UniBeast Guide.

These are the items that need to be checked in the MultiBeast installer:
UserDSDT or DST-Free Installation
Drivers & Bootloaders -> Drivers -> Audio -> Realtek AKC8xx -> Without DSDT -> ALC898
Drivers & Bootloaders -> Drivers -> Disk -> 3rd Party SATA
Drivers & Bootloaders -> Drivers -> Disk -> 3rd Party eSATA
Drivers & Bootloaders -> Drivers -> Disk -> TRIM Enabler -> 10.8.3 TRIM Patch
Drivers & Bootloaders -> Drivers -> Miscellaneous -> FakeSMC
 v5.1.61
Drivers & Bootloaders -> Drivers -> Miscellaneous -> FakeSMC
 v5.1.61 Plugins
Drivers & Bootloaders -> Drivers -> Miscellaneous -> USB 3.0 - Universal
Drivers & Bootloaders -> Drivers -> Network -> Intel - hnak’s AppleIntelE1000e
Drivers & Bootloaders -> Bootloaders -> Chimera v2.0.1 r2109
Customization -> Boot Options -> Generate CPU States
Customization -> Boot Options -> GraphicsEnabler=No
Customization -> System Definitions -> Mac Pro -> Mac Pro 3.1

Probably a good idea to run Disk Utility and repair permissions at this point. Then shut down the machine and install and reconnect you display to the GeForce GTX card. Remember to set your primary display to PCI-E in the BIOS:

Advanced -> System Agent Configuration -> Graphics Configuration -> Primary Display: PCI-E

Now boot up. You should be running fine. Even USB3 should working... but there is an issue. I found that any time I connected a LaCie Rugged USB3 drive to a USB3 port it would hang the machine. It was fine connected to USB2 but what good it that, right? All my other USB3 drives were fine. There is a fix tho. You just need to replace the USB3 extension that Multibeast installs with this one and repair permissions once you are done.

In Part 3 I've posted some benchmarks and my closing thoughts...

Ethical Statement


DaVinci Resolve on a Hackintosh - Part 1

The Parts

I currently run DaVinci Resolve (and FCPX) on a CustoMac/Hackintosh. While Grant Perry from Blackmagic has stated that the new Mac Pro is an awesome machine to run DaVinci Resolve 10 on, it is still a little way off. This article explains why I built a Hackintosh and outlines my set-up for those that might want to do the same.

I am first and formost a Director and DoP. The post production process however has always interested me and over the years I’ve taught myself the process of editing and grading. Some projects I work on have budgets that allow the edited and grading to be outsourced to post production facilities but on personal projects and smaller low budget jobs I’m happily to shoot, edit and grade. Many of these projects have been finished on a full spec late 17″ MacBook Pro. Running DaVinci Resolve on such a machine is slow but you can manage if it’s a simple HD project that only needs a simple grade.

So last year I started looking at my options for a more suitable machine to run DaVinci Resolve. The iMac looked ok and a fully specced 27″ machine looked like a good option. I was looking at spending around £2500… Then my Blackmagic Cinema Camera arrived. And my needs changed.

To get the most out of the BMCC (which shoots 2.5K RAW) I would need a lot of power… mostly GPU power. Looking at the iMac spec it was clear that while it would be ok it would be pushed to it’s limit from the start. So I then started looking at the Mac Pro. A machine that on the surface looked to be much more expandable. The more I looked into it the more I found that the hardware was so out of date that it was really silly spending money on a system that was long overdue for an update. I was not the only one. Most of the Mac Pro users have been waiting for a proper update for a few years. Apple had been promising an update was in the wings but there was still no sign of it when I started this process (Today, 10 June 2013, Apple announced the New Mac Pro).

I had a list of things I wanted from a machine but 2 were essential:
Thunderbolt – I have a Promise Pegasus R6 RAID that I use for my projects and have invested in Thunderbolt devices.
GPU power – I wanted to run at least 2 GeForce GTX570/580/670/680 cards with 2GB RAM or more for DaVinci Resolve.

The iMac has Thunderbolt but I was limited to a single GeForce GTX680MX 2GB GPU. The Mac Pro has no way of supporting Thunderbolt and I’d need an external expansion chassis to run the GPUs I wanted. So it seemed I was out of luck and would have to wait for the mythical future Mac Pro.

I then started researching Windows machines. Seemed I could build a serious machine that would be more than powerful enough to run Resolve but would need to move to Windows. Not ideal. I’ve been a Mac user for over 18yrs. All my past and current project files are Mac based. Sure I could convert them to Premier Pro projects and port them over but thats a lot of work. I also rely on working with other editors that are Mac based and Windows also does not fully support ProRes workflows.

This brought me to the Hackintosh. Could this be a temporary solution? I was not keen on the idea of running a hack but I thought to myself “this would be a temporary thing and if it was not stable I could always intall Windows…”

So I set myself a budget of £2000 and began my research on what parts would work. My aim was not to built the most powerful machine but rather to build a stable machine that included Thunderbolt and would run Resolve comfortably. My evenings and weekends were spent looking at component specs and then researching how stable other had found them in a Hackintosh system. I eventually put together a shopping list. The bottom line was just short of £2350. £350 over budget but I have upped the spec on a few items.

Before we jump into the build and the performance of the machine lets look at that shopping list and why I chose each item:

Asus P8Z77-V Premium Motherboard
I wanted Thunderbolt which limited my to very few rather expensive Z77 motherboards. If I did not want Thunderbolt I could have gone for a much cheaper Z77 motherboard or the X79 motherboards which would have given me more performance options. This ASUS motherboard also offer better PCIe configurations than most which meant in theory I would get more benefit from the GPUs.

Intel Core i7-3770K CPU
This is the fastest processor available for the Z77 motherboard and matched the highest spec available in the iMac. If I had gone with the X97 motherboard (and no Thunderbolt) I could have run a much more powerful CPU.

2 x EVGA NVIDIA GTX 670 FTW 4GB DDR5 PCI-E Graphics Card
I wanted enough power to run DaVinci Resolve smoothy. I also wanted enough GPU RAM for 2K and higher resolutions (BMCC shoots in 2.5K RAW). The 670 was a lot cheaper than the 680 with only a small hit on performance.

SanDisk Extreme 240GB SATA SSD
A fast SSD for the system to run on. Did not need a huge system drive as all my footage is stored on my Thunderbolt RAID.

2 x Corsair 16GB 1600MHz DDR3 Vengeance Memory Kit
32GB of RAM, the maximum that can be installed on a Z77 motherboard.

TP-LINK TL-WDN4800 N900 Wireless PCI Express Adapter
The ASUS motherboard includes WIFI and Bluetooth on the motherboard but they are not seen by Mac OSX.

Corsair HX750 Professional PSU
A reliable power supply with enough overhead to drive the 2 GPUs.

Corsair Hydro Series H100i Liquid Cooler for CPU
Quiet liquid cooling for the CPU. There are much cheaper options out there but this is the one I ended up selecting.

Corsair Obsidian 650D Mid Tower Case
A simple clean case to build the system into. I nice little feature of this case is that it has a SATA slot onto to connect SSD’s or drives. Perfect for dumping footage from the SSDs used in the BMCC or backing up projects to naked SATA drives.

Asus PB278Q 27″ Widescreen
A nice 27″ matte screen for my GUI.

OS X Mountain Lion

OS X 10.8.3 works well and has been stable. You’ll need to buy a copy from the App Store for your build.

To help with the your own build all the above parts are listed on my Amazon UK Store and this Amazon US Store

SanDisk 16GB USB Flash Drive
A USB flash drive for the installation process.

To help with the your own build all the above parts are listed on my Amazon UK Store and this Amazon US Store

I already own a USB Apple Extended Keyboard and A Wacom Intuos 5 so there was no need for me to buy a keyboard and mouse.

Follow onto Part 2, The Build…

Ethical Statement


Look what landed on my desk today - Sony NEX-5

So I got back from lunch today to find this waiting for me on my desk:
nex-5-arrives

The new Sony Alpha NEX-5 with 18-55mm f/3.5-5.6 and 16mm f/2.8. A little delivery from Sony that will be used to shoot a short film I'm working on. More details in the coming weeks.
